Cross roller bearing RE series

Cross Roller Bearing RE Series - High-Precision Outer Ring Rotation Solution

When you need exceptional outer ring rotation accuracy for your precision machinery, the Cross roller bearing RE series delivers the performance you demand. This specialized bearing design features an integral outer ring and split inner ring configuration, making it the optimal choice for applications where the outer housing requires superior rotational precision. The product eliminates common issues found in traditional bearings by providing simultaneous radial, axial, and moment load capacity within a single compact unit, reducing your assembly complexity and space requirements.





Technical Structure and Working Principle

The RE series employs a unique structural design that sets it apart from standard bearing configurations. The solid, integrated outer ring provides exceptional rigidity and rotational stability. The inner ring consists of two separate pieces, allowing for easier installation and maintenance access.

Inside the bearing raceway, cylindrical rollers are positioned orthogonally at 90-degree intervals within precisely machined V-grooves. This crossed arrangement enables the bearing to handle multi-directional loads simultaneously. Roller spacers prevent direct contact between adjacent rollers, reducing friction and extending operational life.

The working principle relies on the orthogonal roller arrangement to distribute loads effectively across multiple contact points. When you apply radial forces, one set of rollers carries the load. Axial forces engage the perpendicular roller set. Moment loads are handled by the combination of both roller sets working together.

Technical Specifications

Performance Advantages

Superior Load Distribution

The crossed roller configuration provides exceptional load-carrying capacity across multiple directions. You benefit from reduced bearing count in your designs since one RE series bearing replaces multiple conventional bearings.

Enhanced Rotational Accuracy

The integral outer ring design delivers superior running precision when your application requires outer ring rotation. This eliminates common accuracy issues associated with split outer ring designs.

Compact Design Benefits

The thin-wall construction minimizes installation space requirements. Your equipment benefits from weight reduction without compromising structural integrity or load capacity.

Low Friction Operation

The orthogonal roller arrangement with precision spacing reduces internal friction. This translates to smoother operation, lower power consumption, and extended service life for your machinery.

​​​​​​​

Primary Applications

Industrial Robotics

RE series bearings excel in robotic joint applications where precise positioning is critical. The bearing handles complex load combinations from robot arm movements while maintaining accuracy throughout operational cycles.

Machine Tool Rotary Tables

Machining centers utilize these bearings in indexing tables and workholding fixtures. The high moment load capacity supports heavy workpieces while maintaining positioning accuracy during cutting operations.

Medical Equipment

CT scanner gantries and surgical robot joints rely on RE series bearings for smooth, vibration-free rotation. The low noise characteristics and precision operation are essential for medical imaging quality.

Precision Measuring Instruments

Coordinate measuring machines and optical inspection systems use these bearings in rotating measurement heads. The exceptional runout accuracy ensures measurement repeatability and reliability.

Selection Considerations

When specifying the Cross roller bearing RE series for your application, consider the load magnitude and direction. Calculate your radial, axial, and moment loads to ensure proper sizing. Operating speed affects lubrication requirements and temperature generation.

Natural variables impact fabric determination and fixing necessities. High-temperature applications may require uncommon warm treatment. Sullied situations require fitting fixing solutions.

Precision prerequisites decide the suitable exactness lesson. P4 and P2 grades give the most noteworthy accuracy for basic applications, whereas P6 and P0 grades suit common mechanical use.

Quality and Manufacturing Excellence

Our 30-year bearing industry involvement guarantees reliable quality in each item we deliver. We keep up strict quality control all through the fabricating handle, from crude fabric review to last testing.

Each bearing experiences comprehensive testing counting vibration investigation, dimensional confirmation, and stack capacity approval. Our three-level quality control framework accomplishes over 99.9% capability rates for wrapped up products.

The secluded generation approach diminishes lead times whereas keeping up exactness benchmarks. Standard setups transport inside 48 hours from our broad stock, whereas custom determinations are conveyed in 70% of ordinary industry timeframes.

Technical Bolster and Service

Our building group gives comprehensive specialized back for bearing determination and application optimization. We offer on-site mapping administrations for substitution orientation when unique details are unavailable.

Installation direction guarantees legitimate mounting and preload settings for ideal execution. Our specialized discussion benefit makes a difference troubleshoot operational issues and suggests upkeep strategies.

For technical inquiries or application assistance, contact our engineering team at auto@lyautobearing.com. We provide detailed technical documentation and application-specific recommendations to ensure your Cross roller bearing RE series selection meets all performance requirements.
